Heat Seal SW-3614 Semi-Automatic Shrink Bundler Main View
Pro PacPRO PAC
Heat Seal BrandHeat Seal
Semi-AutomaticSemi-Automatic

Heat Seal SW-3614 Semi-Automatic Shrink Bundler

Large 36 inch wide seal bar with 14 inch height opening for versatile product bundling
Heavy-duty hot knife seal system with film clamps and RS-5 Plus digital controller
Power assisted top and bottom film unwind with roller infeed and belt outfeed conveyors
Heat Seal SW-3614 Semi-Automatic Shrink Bundler Main View
Heat Seal SW-3614 Semi-Automatic Shrink Bundler Main View
PricePricing available on request
Semi-automatic operation
36" wide seal capacity
Heavy-duty bundling • Digital control
Selling Only Trusted Industry Brands:

TechnicalSpecifications

Semi-automatic shrink bundling performance with heavy-duty hot knife seal system and digital control. Complete specifications for the Heat Seal SW-3614 featuring RS-5 Plus controller, power-assisted film unwind, and 36-inch wide sealing capacity for trayed product bundling applications.

SPECIFICATION
SW-3614 CONFIGURATION
Model Type
Semi-Automatic Shrink Bundler
Film Capacity
36" Wide (91.4 cm)
Seal Width
36" (91.4 cm)
Opening Height
14" H opening
Max Package Height
13"H (33 cm)
Control System
RS-5 Plus digital controller with easy controls
Seal System
Heavy-duty hot knife with film clamps
Overall Dimensions
48"L × 40"W × 77"H (122L × 102W × 196H cm)
Working Height
35" (89 cm)
Power Requirements
115 Volts, 12 Amps, Single Circuit with Ground
Weight
450 lbs (204 kg)

Why the Heat Seal SW-3614 Leads Semi-Automatic Bundling

Semi-automatic shrink bundling with heavy-duty hot knife sealing system-perfect for trayed products and medium-volume operations. Features RS-5 Plus digital controller, power-assisted film handling, and 36-inch sealing capacity for reliable bundling of various product sizes requiring consistent quality and operator control.

Heavy-Duty Sealing System

Hot knife seal system with film clamps provides reliable sealing for various bundling films with consistent results. RS-5 Plus digital controller offers precise temperature and time control with easy-to-understand operation for optimal seal quality.

Large Capacity Opening

36" wide by 14" high opening accommodates various product sizes including trayed products and multi-pack items. Manually adjustable seal height provides flexibility for different package dimensions while maintaining optimal sealing performance.

Operator-Friendly Design

Single plug 115V power supply with heavy-duty circuit breaker simplifies installation. Air actuated seal head with dual palm buttons ensures safe operation while dual magnetic hold downs secure products during sealing.

Efficient Material Handling

Power assisted top and bottom film unwind reduces operator fatigue and ensures smooth film feeding. Roller infeed and belt outfeed conveyors provide seamless product flow through the bundling process.

Flexible Configuration Options

Available in standard or stainless steel models with 220V electrical wiring option. Heavy-duty adjustable levelers and locking casters enable precise positioning and easy relocation as production needs change.

Proven ROI & Reliability

Reduces labor costs while improving bundling consistency and product presentation. Heavy-duty construction ensures long-term reliability with minimal maintenance requirements for continuous production operations.

Get Your Custom Quote

Frequently AskedQuestions

What types of products work best with the SW-3614 shrink bundler?
The SW-3614 is designed for trayed products and multi-pack items up to 13" high and 36" wide. It's perfect for laundry products, food trays, beverage multi-packs, and other products requiring secure bundling for retail presentation.
How does the hot knife sealing system work on the SW-3614?
The heavy-duty hot knife system cuts and seals simultaneously using digitally controlled temperature and time settings. Film clamps hold the material in place while the air-actuated seal head creates consistent, strong seals across the full 36-inch width.
What are the power requirements and installation needs for the SW-3614?
The SW-3614 requires 115 Volts, 12 Amps, single circuit with ground connection. It features a single plug design for easy installation. Optional 220V electrical wiring is available, and the unit includes adjustable levelers and locking casters for positioning.
Can the SW-3614 handle different film types and thicknesses?
Yes, the hot knife seal system with adjustable temperature and time controls accommodates various bundling film types and thicknesses. The RS-5 Plus controller provides precise settings for optimal sealing of different film materials.
What safety features are built into the SW-3614 bundler?
The SW-3614 includes dual palm button controls for safe two-hand operation, dual magnetic hold downs to secure products, heavy-duty circuit breaker protection, and air-actuated seal head for consistent, controlled sealing cycles.
